setup hfgd2.0 quickly

Diagramm könnte hier zeigen: Die Docker-Container-Architektur mit UI, API, MongoDB, Synapse, MinIO, Keycloak und LiveKit sowie deren Netzwerkverbindungen

create a new stack with the compose
add the .env sample and change the required fields
copy the homeserver.yaml to the synapse data folder and change the variables there

create the .log.config and .signing.key files and media_store folder

the synapse signing key can be generated using the synapse-init service using:
pip install matrix-synapse && \
python -m synapse.app.homeserver \
--generate-keys \
--config-path /data/homeserver.yaml \
--keys-directory /data \
--server-name <MATRIX DOMAIN>

fix the file permissions for the signing key:

chown 991:991 _.signing.key chmod 644 _.signing.key
remove the synapse-init service
create a synapse admin user with register_new_matrix_user -c /data/homeserver.yaml
create the ui config file /usr/share/nginx/html/config/config.js

compose

services:
  ui:
    image: registry.hfg.gd:5050/hfgd20_dev/ui:main
    networks:
      - traefik_default
    depends_on:
      - api
    # ports:
    #   - 8080:80
    volumes:
      - ui_data:/usr/share/nginx/html/config
    deploy:
      mode: replicated
      replicas: 1
      update_config:
        parallelism: 1
        delay: 10s
      restart_policy:
        condition: on-failure
      labels:
        - 'traefik.enable=true'
        - 'traefik.port=80'
        - 'traefik.docker.network=traefik_default'
        - 'traefik.http.routers.${STACK_NAME}-ui.rule=Host(`${STACK_NAME}-ui.${DOMAIN}`)'
        - 'traefik.http.services.${STACK_NAME}-ui.loadbalancer.server.port=80'
        - 'traefik.http.services.${STACK_NAME}-ui.loadbalancer.server.scheme=http'

  api:
    image: registry.hfg.gd:5050/hfgd20_dev/slv-api:main
    networks:
      - traefik_default
      - mongo
    depends_on:
      - mongo
      - synapse
      - minio
    # ports:
    #   - 8081:80
    deploy:
      mode: replicated
      replicas: 1
      update_config:
        parallelism: 1
        delay: 10s
      restart_policy:
        condition: on-failure
      labels:
        - 'traefik.enable=true'
        - 'traefik.port=80'
        - 'traefik.docker.network=traefik_default'
        - 'traefik.http.routers.${STACK_NAME}-api.rule=Host(`${STACK_NAME}-api.${DOMAIN}`)'
        - 'traefik.http.services.${STACK_NAME}-api.loadbalancer.server.port=80'
        - 'traefik.http.services.${STACK_NAME}-api.loadbalancer.server.scheme=http'
    environment:
      - URL=${STACK_NAME}-api.${DOMAIN}
      - API_ENV=prod
      - PORT=$PORT
      - CORS_ORIGINS=$CORS_ORIGINS
      - MONGO_USER=$MONGO_USER
      - MONGO_PASSWORD=$MONGO_PASSWORD
      - MONGO_URL=$MONGO_URL
      - MONGO_DATABASE=$MONGO_DATABASE
      - S3_ACCESS_KEY=$MINIO_ROOT_USER
      - S3_SECRET_KEY=$MINIO_ROOT_PASSWORD
      - S3_BUCKET_SLIDES=$MINIO_BUCKET_SLIDES
      - S3_BUCKET_SPACE_ICONS=$MINIO_BUCKET_SPACE_ICONS
      - S3_BUCKET_AVATARS=$MINIO_BUCKET_AVATARS
      - S3_REGION=$MINIO_REGION
      - ALLOWED_PKCE_CLIENTS=$ALLOWED_PKCE_CLIENTS
      - ALLOWED_CLIENT_CLIENTS=$ALLOWED_CLIENT_CLIENTS
      - LIVEKIT_API_KEY=$LIVEKIT_API_KEY
      - LIVEKIT_API_SECRET=$LIVEKIT_API_SECRET
      - LIVEKIT_API_URL=$LIVEKIT_API_URL
      - MATRIX_BASE_URL=$MATRIX_BASE_URL
      - MATRIX_USER=$MATRIX_USER
      - MATRIX_PASSWORD=$MATRIX_PASSWORD
      - KEYCLOAK_URL=$KEYCLOAK_URL
      - KEYCLOAK_REALM=$KEYCLOAK_REALM
      - KEYCLOAK_CLIENT_ID=$KEYCLOAK_CLIENT_ID
      - KEYCLOAK_CLIENT_SECRET=$KEYCLOAK_CLIENT_SECRET
      - DISPATCH_ALL_AGENTS=$DISPATCH_ALL_AGENTS

  mongo:
    image: mongo:4.4.17-focal
    deploy:
      restart_policy:
        condition: any
      mode: replicated
      replicas: 1
    environment:
      MONGO_INITDB_ROOT_USERNAME: $MONGO_USER
      MONGO_INITDB_ROOT_PASSWORD: $MONGO_PASSWORD
    networks:
      - mongo
    # ports:
    #   - 27017:27017
    volumes:
      - mongo_data:/data/db

  # This service is used to initialize the Synapse homeserver configuration.
  # Remove it after the initial setup is done.
  synapse-init:
    image: python:3.11
    volumes:
      - synapse_data:/data
    working_dir: /data
    entrypoint: /bin/bash
    command: -c "tail -f /dev/null"
    # uncomment this after creating the initial homeserver.yaml
    # command: >
    #   -c "
    #   pip install matrix-synapse &&
    #   python -m synapse.app.homeserver
    #     --generate-keys
    #     --config-path /data/homeserver.yaml
    #     --keys-directory /data
    #     --server-name \${STACK_NAME}-synapse.\${DOMAIN}
    #   "

  synapse:
    image: matrixdotorg/synapse:latest
    volumes:
      - synapse_data:/data
    networks:
      - matrix
      - traefik_default
    environment:
      - SYNAPSE_SERVER_NAME=${STACK_NAME}-synapse.${DOMAIN}
      - SYNAPSE_REPORT_STATS=yes
    depends_on:
      - postgres
    # ports:
    #   - 8008:8008
    deploy:
      mode: replicated
      replicas: 1
      update_config:
        parallelism: 1
        delay: 10s
      restart_policy:
        condition: on-failure
      labels:
        - 'traefik.enable=true'
        - 'traefik.port=8008'
        - 'traefik.docker.network=traefik_default'
        - 'traefik.http.routers.${STACK_NAME}-synapse.rule=Host(`${STACK_NAME}-synapse.${DOMAIN}`)'
        - 'traefik.http.services.${STACK_NAME}-synapse.loadbalancer.server.port=8008'
        - 'traefik.http.services.${STACK_NAME}-synapse.loadbalancer.server.scheme=http'

  postgres:
    image: postgres:14
    container_name: matrix-db
    # ports:
    #   - 5432:5432
    restart: unless-stopped
    networks:
      - matrix
    volumes:
      - postgres_data:/var/lib/postgresql/data
    environment:
      - POSTGRES_DB=$POSTGRES_DB
      - POSTGRES_USER=$POSTGRES_USER
      - POSTGRES_PASSWORD=$POSTGRES_PASSWORD
      - POSTGRES_INITDB_ARGS= --encoding='UTF8' --lc-collate='C' --lc-ctype='C'

  minio:
    image: minio/minio:RELEASE.2022-09-25T15-44-53Z
    # ports:
    #   - 9000:9000
    deploy:
      mode: replicated
      replicas: 1
      update_config:
        parallelism: 1
        delay: 10s
      restart_policy:
        condition: on-failure
      labels:
        - 'traefik.enable=true'
        - 'traefik.port=9000'
        - 'traefik.docker.network=traefik_default'
        - 'traefik.http.routers.${STACK_NAME}-minio.rule=Host(`${STACK_NAME}-minio.${DOMAIN}`)'
        - 'traefik.http.services.${STACK_NAME}-minio.loadbalancer.server.port=9000'
        - 'traefik.http.services.${STACK_NAME}-minio.loadbalancer.server.scheme=http'
    command: server /data --console-address ":9001"
    volumes:
      - minio_data:/data
    networks:
      - traefik_default
    environment:
      MINIO_ROOT_USER: $S3_ACCESS_KEY
      MINIO_ROOT_PASSWORD: $S3_SECRET_KEY
      MINIO_SERVER_URL: https://${STACK_NAME}-minio.${DOMAIN}

volumes:
  ui_data:
  postgres_data:
  synapse_data:
  minio_data:
  mongo_data:

networks:
  matrix:
  mongo:
  traefik_default:
    external: true

…other docs will folllow
